Description
xGEN-50 Epoxy Resin is a medium-viscosity, all-purpose resin system designed for art, woodworking, encapsulation, and adhesion applications. With a 2:1 mix ratio, it offers a working time of 45 minutes, cures touch-dry in 3 hours, and achieves full internal cure in 24 hours. Its non-yellowing formula makes it ideal for photo lamination, fiber-reinforced products, carbon fiber applications, and general-purpose adhesives. GEN-50 provides a crystal-clear finish with high gloss and excellent adhesion to various materials like wood, metal, glass, and stone.
Technical Details
x
| Property | High | Medium-High | Medium | Medium-Low | Low | Very Low | Lowest |
|---|---|---|---|---|---|---|---|
| Non-Yellowing | Zenith | Zenith 450 | Clear Cast | Art Cast | Deep Cast | Art FC | Gen-50 |
| Casting Depth | Zenith (75 mm) | Zenith 450 (75 mm) | Deep Cast (50 mm) | Clear Cast (25 mm) | Art Cast (15 mm) | Art FC (8–10 mm) | Gen-50 (8–10 mm) |
| Viscosity | Art FC (Very Thick - Honey-like) | Gen-50 (Mid) | Art Cast (Low) | Deep Cast (Low) | Zenith 450 (Low) | Clear Cast (Very Thin) | Zenith (Very Thin) |
| Pot Life | Zenith (8 hours) | Art Cast (8 hours) | Deep Cast (8 hours) | Zenith 450 (4 hours) | Clear Cast (2 hours 30 m) | Gen-50 (1 hour) | Art FC (1 hour) |
| Casting Below 20°C | Clear Cast (great) | Art FC (Great) | Zenith 450 (Great) | Gen-50 (Great) | Zenith (Good) | Art Cast (Poor) | Deep Cast (Poor) |
Features
x
| Feature | Description |
|---|---|
| Mix Ratio | 2 : 1 |
| Working Time | 45 Minutes |
| Overcoat Time | 2 Hours 30 Minutes |
| Touch Dry | 3 Hours |
| Cure to Handle | 12 Hours |
| Full Internal Cure | 24 Hours |
| Casting Thickness | Up to 8-10mm |
| Viscosity | Medium Viscosity |
| Clarity | Crystal clear, high gloss |
| Effects Retention | Retains color patterns, cells, and artistic effects |
| UV Protection | Non-yellowing, retains clarity |
| Self-Leveling | Yes |
| Bubble Resistance | Use artist blow torch within 1 hour for best results |
| Compatibility | Works with pigment paste, powder paste, alcohol inks, acrylics, silicon oil & oil-based paints |
